Fujitsu AOYG30LETL - Outdoor Unit Heat Exchanger Component Parts

Ref.
56 Strainer Assy 9372524015
59 Check Joint Assy 9372802038
52 Condenser A Sub Assy 9374420308
53 Condenser A Assy 9374433056
58 4-way Valve 9900164010
57 4-way Valve Assy 9374425198
61 Pressure Switch 9900186012
54 Inlet Pipe (Cond) A Assy 9373461067
55 Outlet Pipe (Cond) A Assy 9374266104
51 Expansion Valve Assy 9370947144
60 Muffler 9372369050
Part numberDescription
OUTDOOR UNIT
2013.02.07 26
51
52
54
55
56
53
61
59
58
60
57
