Fujitsu AOYG30LFT User Manual

12V
K101
DW12D1
C108
3.3
<LE>
L102
N200500K1D7C
3 2
4 1
12V
CN100
172520-2
POWER RELAY CONTROL
1 2
SA100
RA-302M
L101
RCH3818-022PF07
C106
3.3
<LE>
4
3
2
1
CT OUT
W21
GRAY
B
C103
3.3
<LE>
L100
RCH3818-022PF07
1
2
43
C104
0.022
<YE>
C100
3.3
<LE>
VA100
470V
<TNR>
VA101
470V
<TNR>
FH100
FH101
PFC5000-0502 x 2
F100
FSL 10A
250V
W2 WHITE B
W1 BLACK B
W18 WHITE B W17 BLACK B
W3 GREEN B
W19 BLACK B
W20 WHITE B
L
N
L
N
TO INDOOR UNIT
EARTH
AC VOLT OUT
W29 BROWN B
W25 ORANGE B
W28 ORANGE B
W27 ORANGE B
W26 ORANGE B
PTC OUT
C101
0.033
<YE>
C102
0.033
<YE>
C105
0.022
<YE>
2011.01.05 11
OUTDOOR UNIT POWER SUPPLY PCB ASSEMBLY K05CW-0900HUE-FL0
POWER SOURCE AC230V 50Hz
W9 BLACK B
