Fujitsu AOYG36KATA - Indoor Unit Capacity Table

¢
Model: AOYG45KATA
Unit: mm
Top view
Bottom view
Side viewFront view
940
996.2
266.7
Pipe & Cable port
Rear view
Ф28: Cable port
Pipe port
650
35.748
143147
39.8
53.9 Liquid
40 320
354.8
62.9 Gas
12.9
297.2
(Gas valve)
(Liquid valve)
Ф28
Cable port
1-1/8
(29)
Pipe port
23.4
129.1
85.3
50
29
Pipe port
A
95
89
A
3 Way valve
(Liquid)
3 Way valve
(Gas)
320
139.8
96
40 5
Ф28
Cable port
120
Pipe port
55
25
50
B
B
50
25
141.9
70
67
Pipe port
264.6
351.9
47.6
15.262.6
15.6
2-2. Outdoor unit - (01-14) - 2. Dimensions
GENERAL INFORMATION GENERAL INFORMATION
