¢ Louvers and motors
21
23
2224
A
Step Motor
Louver Assy
Motor Cover
Wire (Step Motor)
9381693009
9381712007
9900885007
9381354009
9710175008
Motor Case Assy
Parts No.
Description
Ref
No.
21
22
23
24
Detail A
2-1. Model: UTG-UKYC-W - (02-4) - 2. Cassette grille (optional part) parts list
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST
