6. THERMISTOR removal

6-1 PIPE THERMISTOR

6-2 ROOM THRMISTOR

1) Remove the mounting

screws(4 places)

3) Remove the

THERMISTOR SPRING.

Remove the THERMISTOR.

4) Remove the

THERMISTOR.

screw

03-05

7. DRAIN PAN removal

screw

2) Remove the PIPE PANEL.

1) Remove the mounting

screws(2 places)

2) Remove the DRAIN PAN.

Attention!!

When remove the screw,

please affix and remove the hand.
