OUTDOOR UNIT
Description
Ref.
No.
AOY18FNDN
Ord.
Q' ty
2 Fan Guard 9371187013
4 Emblem-Rear 9351355005
5 Front Panel 9371924014
7 Cover (Switch) Assy 9366398004
9 Side Panel-R 9371927015
12 Base Assy 9371920054
13-1 3-Way Valve Assy 9314674013
13-2 2-Way Valve Assy 9314681011
16 Condenser Assy 9314473012
29 Separate Wall 9371933016
32 Control Box 9371935010
34 Capacitor, DS451355 9900089108
37 Capacitor (Running) 9307588174
38 Clamp Metal (Capacitor) 9351770013
39 Propeller Fan Assy 9314812019
41 Motor, Induction 9602277018
45-1 Motor Bracket Top 9371931012
45-2 Motor Bracket Center 9371930015
45-3 Motor Bracket Bottom 9371932019
210 Relay 9900074012
527 Protective Net 9371934013
734 Top Panel 9371925011
815-3 Terminal-5P 9900203023
46 Compressor Assy 9372558027
--- Wire Assy (Comp. ) 9314792007
--- Strainer 9369287008
--- Capillary Assy 9372197066
--- Fuse Holder 0501456016
982-1
982-2
Double Cord Clamp A 9359822011
Double Cord Clamp B 9359823018
--- Outdoor Thermostat 9352553004
--- Special Nut M5 9300301015
55 Special Nut M8 9355091008
64 Side Panel-L 9371926018
85 Valve Plate 9371928012
Part No.
Description
Ref.
No.
Ord.
Q' ty
Part No.
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
AOY18UNDNL
2 Fan Guard 9371187013
4 Emblem-Rear 9351355005
5 Front Panel 9371924014
7 Cover (Switch) Assy 9366398004
--- BR Sheet 9363708059
--- Wire Assy (Comp. ) 9314792007
9 Side Panel-R 9371927015
218-3 Relay 9900264017
12 Base Assy 9371920054
--- Controller PCB Assy 9704299055
13-1 3-Way Valve Assy 9314674013
--- Receiver Tank Sub Assy 9372320013
13-2 2-Way Valve Assy 9314681011
259 Muffler 9372369012
16 Condenser Assy 9314475016
272 Strainer 9369287008
29 Separate Wall 9371933023
343 Solenoid 9900165024
32 Control Box 9371935010
--- Control Box-B 9371936017
34 Capacitor, DS451355XPQB 9900089108
37 Capacitor (Running) 9307588174
--- Capillary Assy 9372197127
38 Clamp Metal (Capacitor) 9351770013
39 Propeller Fan Assy 9314812019
41 Motor, Induction 9602277018
--- Fuse 0600222512
45-1 Motor Bracket Top 9371931012
45-2 Motor Bracket Center 9371930015
45-3 Motor Bracket Bottom 9371932019
46 Compressor Assy 9372558027
--- Special Nut M5 9300301015
55 Special Nut M8 9355091008
344 4-Way Valve 9970036019
527 Protective Net 9371934013
734 Top Panel 9371925011
815-3 Terminal-5P 9900203023
982-1 Double Cord Clamp A 9359822011
982-2 Double Cord Clamp B 9359823018
--- Transformer, Power 9900039011
--- Heat Exchanger Thermistor 9900043032
64 Side Panel-L 9371926018
--- Discharge Temp. Thermistor 9900038014
--- Outdoor Temp. Thermistor 9900037031
85 Valve Plate 9371928012
--- Thermistor Spring-A 313728262708
