Fujitsu AS* G09LECB User Manual

 Indoor units: 9,000 Btu + 9,000 Btu + 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 21.53 3.10 21.02 3.17 20.51 3.23 20.00 3.30 19.48 3.36
14 12 26.21 3.15 25.58 3.21 24.96 3.28 24.34 3.34 23.71 3.41
23 19 30.25 3.19 29.53 3.26 28.81 3.33 28.09 3.39 27.37 3.46
32 28 32.17 3.01 31.40 3.07 30.63 3.13 29.87 3.20 29.10 3.26
41 37 33.72 2.98 32.91 3.04 32.11 3.10 31.31 3.16 30.50 3.23
47 43 35.60 3.13 34.75 3.19 33.90 3.26 33.05 3.33 32.21 3.39
50 47 36.18 3.12 35.31 3.18 34.45 3.25 33.59 3.31 32.73 3.38
59 50 37.92 3.09 37.02 3.15 36.11 3.22 35.21 3.28 34.31 3.35
68 59 38.55 2.66 37.63 2.72 36.72 2.78 35.80 2.83 34.88 2.89
75 65 40.70 2.65 39.73 2.71 38.76 2.76 37.79 2.82 36.82 2.87
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 6.31 3.10 6.16 3.17 6.01 3.23 5.86 3.30 5.71 3.36
-10.0 -11.1 7.68 3.15 7.50 3.21 7.32 3.28 7.13 3.34 6.95 3.41
-5.0 -7.2 8.87 3.19 8.65 3.26 8.44 3.33 8.23 3.39 8.02 3.46
0.0 -2.2 9.43 3.01 9.20 3.07 8.98 3.13 8.75 3.20 8.53 3.26
5.0 2.8 9.88 2.98 9.65 3.04 9.41 3.10 9.18 3.16 8.94 3.23
8.3 6.1 10.43 3.13 10.18 3.19 9.94 3.26 9.69 3.33 9.44 3.39
10.0 8.3 10.60 3.12 10.35 3.18 10.10 3.25 9.85 3.31 9.59 3.38
15.0 10.0 11.11 3.09 10.85 3.15 10.58 3.22 10.32 3.28 10.06 3.35
20.0 15.0 11.30 2.66 11.03 2.72 10.76 2.78 10.49 2.83 10.22 2.89
23.9 18.3 11.93 2.65 11.64 2.71 11.36 2.76 11.08 2.82 10.79 2.87
 Indoor units: 9,000 Btu + 9,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 23.82 3.44 23.25 3.51 22.69 3.58 22.12 3.65 21.55 3.72
14 12 28.99 3.49 28.30 3.56 27.61 3.63 26.92 3.70 26.23 3.78
23 19 33.46 3.53 32.66 3.61 31.87 3.68 31.07 3.76 30.27 3.83
32 28 35.58 3.33 34.73 3.40 33.89 3.47 33.04 3.54 32.19 3.61
41 37 37.30 3.30 36.41 3.37 35.52 3.43 34.63 3.50 33.74 3.57
47 43 39.38 3.47 38.44 3.54 37.50 3.61 36.56 3.68 35.63 3.75
50 47 40.02 3.45 39.07 3.53 38.11 3.60 37.16 3.67 36.21 3.74
59 50 41.95 3.42 40.95 3.49 39.95 3.56 38.95 3.64 37.95 3.71
68 59 42.65 2.95 41.63 3.01 40.61 3.07 39.60 3.14 38.58 3.20
75 65 45.02 2.94 43.95 3.00 42.88 3.06 41.81 3.12 40.73 3.18
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 6.98 3.44 6.82 3.51 6.65 3.58 6.48 3.65 6.32 3.72
-10.0 -11.1 8.50 3.49 8.29 3.56 8.09 3.63 7.89 3.70 7.69 3.78
-5.0 -7.2 9.81 3.53 9.57 3.61 9.34 3.68 9.11 3.76 8.87 3.83
0.0 -2.2 10.43 3.33 10.18 3.40 9.93 3.47 9.68 3.54 9.44 3.61
5.0 2.8 10.93 3.30 10.67 3.37 10.41 3.43 10.15 3.50 9.89 3.57
8.3 6.1 11.54 3.47 11.27 3.54 10.99 3.61 10.72 3.68 10.44 3.75
10.0 8.3 11.73 3.45 11.45 3.53 11.17 3.60 10.89 3.67 10.61 3.74
15.0 10.0 12.29 3.42 12.00 3.49 11.71 3.56 11.42 3.64 11.12 3.71
20.0 15.0 12.50 2.95 12.20 3.01 11.90 3.07 11.61 3.14 11.31 3.20
23.9 18.3 13.20 2.94 12.88 3.00 12.57 3.06 12.25 3.12 11.94 3.18
- 287 -
6-3. Heating capacity 6. Capacity table
