Unit : inch (mm)
OUTDOOR UNIT
14-9/16 (370)
25-19/32 (650)
Air Flow
35-7/16 (900)
1-9/16
(40)
1-7/32
(31)
15/32
(12)
32-7/8 (830)
13/16 (21)
11/32
(9)
15-3/4
(400)
13 (330)
62007.10.10
