2-2. Outdoor unit

¢ Model: AOUH09LPAS1

Unit: in (mm)

4-3/16 (106)17-11/16 (450)

13-7/8 (353)

13 (330)

Pitch of bolts for installation

0 hole

Top view

Side view

Front view

Pitch of bolts

for installation

3/4 (19) 26-1/8 (663) 2-11/16 (68)

21-5/16 (541)

13/16 (20)

1/2 (13)

1-5/16 (33) 1-3/16 (30)

11-7/16 (290)

Airflow

Bottom view

1-7/16 (37)

13-1/16(331)

Drain port Ø1-5/8 (42)

Side view (Valve part)

4-1/4 (184)

4-3/4 (120)

6-11/16 (170)

2-2. Outdoor unit - (01-6) - 2. Dimensions
