• Operation status

* The outdoor temperature zone transition from one to another will stay in that zone for minimum of 30 min.

Combination zone

Heat pump only zone

12 V

Off

0 V

Heater

Fan

Comp. On/Off

Outdoor temperature

(Factory setting)

Outdoor temperature zone *

46.4°F (8°C)

42.8°F (6°C)

-0.4°F (-18°C)

-4°F (-20°C)

NOTE: In following operations, compressor will be on in heat pump prohibition zone.

• Other than heating

• Test run
