Fujitsu ASUH09LPAS User Manual

 Unit: kW, °C
• TC: Total Capacity (kW).
• The data is based on the following conditions:
Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: ADUH07LUAS1
Outdoor temperature
Indoor temperature (°CDB)
15.6 18.3 21.1 23.9 25.6
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.1 1.51 1.47 1.44 1.40 1.37
-10.0 -11.1 1.70 1.66 1.62 1.58 1.54
-5.0 -7.2 1.90 1.85 1.80 1.76 1.71
0.0 -2.2 2.21 2.16 2.10 2.05 2.00
5.0 2.8 2.52 2.46 2.40 2.34 2.28
8.3 6.1 2.58 2.52 2.46 2.40 2.34
10.0 8.3 2.58 2.52 2.46 2.40 2.34
15.0 10.0 2.58 2.52 2.46 2.40 2.34
20.0 15.0 2.47 2.41 2.35 2.29 2.23
23.9 18.3 2.35 2.30 2.24 2.18 2.13
MODEL: ADUH09LUAS1
Outdoor temperature
Indoor temperature (°CDB)
15.6 18.3 21.1 23.9 25.6
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.1 1.94 1.90 1.85 1.80 1.76
-10.0 -11.1 2.19 2.14 2.08 2.03 1.98
-5.0 -7.2 2.44 2.38 2.32 2.26 2.20
0.0 -2.2 2.84 2.77 2.70 2.64 2.57
5.0 2.8 3.24 3.16 3.09 3.01 2.93
8.3 6.1 3.32 3.24 3.17 3.09 3.01
10.0 8.3 3.32 3.24 3.17 3.09 3.01
15.0 10.0 3.32 3.24 3.17 3.09 3.01
20.0 15.0 3.17 3.10 3.02 2.95 2.87
23.9 18.3 3.02 2.95 2.88 2.81 2.74
MODEL: ADUH12LUAS1
Outdoor temperature
Indoor temperature (°CDB)
15.6 18.3 21.1 23.9 25.6
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.1 2.59 2.53 2.47 2.40 2.34
-10.0 -11.1 2.92 2.85 2.78 2.71 2.64
-5.0 -7.2 3.25 3.17 3.09 3.02 2.94
0.0 -2.2 3.79 3.69 3.60 3.51 3.42
5.0 2.8 4.32 4.22 4.12 4.01 3.91
8.3 6.1 4.43 4.33 4.22 4.11 4.01
10.0 8.3 4.43 4.33 4.22 4.11 4.01
15.0 10.0 4.43 4.33 4.22 4.11 4.01
20.0 15.0 4.23 4.13 4.03 3.93 3.83
23.9 18.3 4.03 3.94 3.84 3.74 3.65
MODEL: ADUH18LUAS1
Outdoor temperature
Indoor temperature (°CDB)
15.6 18.3 21.1 23.9 25.6
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.1 3.88 3.79 3.70 3.61 3.51
-10.0 -11.1 4.38 4.27 4.17 4.07 3.96
-5.0 -7.2 4.87 4.76 4.64 4.53 4.41
0.0 -2.2 5.68 5.54 5.41 5.27 5.14
5.0 2.8 6.48 6.33 6.17 6.02 5.86
8.3 6.1 6.65 6.49 6.33 6.17 6.01
10.0 8.3 6.65 6.49 6.33 6.17 6.01
15.0 10.0 6.65 6.49 6.33 6.17 6.01
20.0 15.0 6.34 6.19 6.04 5.89 5.74
23.9 18.3 6.05 5.90 5.76 5.61 5.47
- 284 -
