Page #19 background imageLoading...
Page #19 background image
Item no. Part no. Part name Service part
50 9382185077 Evaporator total assy
51 9901013010 Terminal
52
9711732156 Main PCB (30 model)
9711732163 Main PCB (36 model)
53 9316577008 Thermistor spring B
54 9900627027 Thermistor assy
55 9386988001 Room thermistor holder
56 9711146090 Display assy
57 9711147035 Indicator PCB
58 9603933005 DC fan motor
59 9361756007 Drain hose insulation T
60 9387063004 Link holder assy
61 9900139186 Step motor
62 9387062007 Gear cover assy
63 9900384234 Step motor
64 9387060034 Casing assy
65 9318743012 Pipe bracket
66 9388540009 Drain hose assy
67 9316177017 Drain cap
68 9387055009 Crossflow fan assy
69 9306628017 Bearing C assy
a Box shield assy
b Control box
c PCB holder A
d Control cover
e Motor cover
f Motor cover
g Cable guide
h Casing
2-1. Models: ASUH30LPAS and ASUH36LPAS - (02-5) - 2. Indoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
