Item no. Part no. Part name Service part
1 9383880001 Top panel assy ♦
2 9383779008 Protective net ♦
3 9375361013 Net rubber ♦
4 313728262708 Thermistor spring A ♦
5 9900984038 Thermistor (Heat exchanger temp.) ♦
6 9900727154 Thermistor assy (Evaporator and Compressor temp.) ♦
7 9383607004 Thermo holder ♦
8 9383874000 Right panel sub assy ♦
9 9384997005 Rear pipe cover ♦
10 9709686317 Inverter PCB ♦
11
9711431738 Main PCB (30 model) ♦
9711431745 Main PCB (36 model) ♦
12 9900203085 Terminal ♦
13 9383871016 Base assy ♦
14 313166024302 Drain cap ♦
15 9303029015 Drain assy ♦
16 9383876004 Service panel sub assy ♦
17 9384196019 Front pipe cover ♦
18 9380114000 Emblem rear ♦
19 9383863035 Front panel assy ♦
20 9350680009 Fan guard assy ♦
21 9383336003 Propeller fan ♦
22 9603732011 DC fan motor ♦
23 9383862007 Motor bracket assy ♦
24 9383882005 Left panel sub assy ♦
25 9374420711 Condenser sub assy ♦
— 9711198006
Wire with connector
(P108 on Main PCB—Terminal)
♦
— 9711203038
Wire with connector
(P660 on Main PCB—P662 on Inverter PCB)
♦
— 9711204004
Wire with connector
(P661 on Main PCB—P663 on Inverter PCB)
♦
— 9711205001
Wire with connector
(P350 on Main PCB—P351 on Inverter PCB)
♦
— 9711212009
Wire with connector
(P650 on Inverter PCB—DC fan motor)
♦
— 9711213006
Wire with connector
(P770 on Inverter PCB)
♦
— 9711214003
Wire with connector
(Pressure switch)
♦
a — Separate wall assy —
b — Control box unit —
3-1. Models: AOUH30LPAS1 and AOUH36LPAS1 - (02-7) - 3. Outdoor unit parts list
