62
63
64
61
65
INDOOR UNIT
Louver link sub assy
2007.11.30 19
62 Link Holder 9368563004
65 Step Motor 9900139032
64 Louver Link 9368562007
61 Louver Link Sub Assy 9369347023
63 Louver Spring 9368613006
Ref. Description
Part number
