Fujitsu FI-4120C User Manual
5
of 1
of 1 rating
180 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
7.2 Re
medying T
ypical T
roub
les
101
7
TR
OUBLESHOO
TING
*) F
or details o
n how to
clean dir
ty locations
, see "Chapter
5, D
AIL
Y
CARE."
NO
Clean dirty locations.(*)
Symptom5
Quality of scanned text or lines is unsatisfactory
.
YES
Glass and sheet guides(A
white
portion) clean?
Contact the manufacturer
’
s
authorized service center
.
127
129
Table of Contents
Default Chapter
3
About this Manual
3
How this Manual Is Organized
3
Safety Precautions
11
Symbols Used in this Manual
12
Screen Examples in this Manual
13
Table of Contents
26
1 Preparing the Scanner
28
Checking the Contents of the Scanner Package
29
Names and Functions of Parts
31
Operator Panel
36
2 Installation Ofa Scanner
42
Installing the Scanner
43
Connecting the Scanner to a PC
46
Installing the Scanner Application
53
3 Basic Scanner Operations
54
Turning the Scanner on
55
Loading Documents on the ADF for Scanning
57
Load the Document on the Adf Paper Chute
59
Scanning Documents
63
4 Scanning Various Types of Documents
68
Scanning Different-Width Documents
69
Saving Scanned Images in PDF Format
70
Excluding a Color in the Image(Dropout Color)
75
Detecting Double-Feeds
78
5 Daily Care
82
Cleaning Materials and Locations and Cleaning Cycle
83
Cleaning the ADF
85
6 Replacing Consumables
92
Consumable and Replacement Cycle
93
Replacing the Pad ASY
101
Replacing the Pick Roller
107
7 Troubleshooting
118
Removing Jammed Documents
119
Remedying Typical Troubles
122
Items to Check before Contacting the Agent Where You Bought the Scanner
141
Checking Labels on the Scanner
145
8 Adf and Paper Specification
148
Document Size
149
Document Quality
150
Maximum Document Loading Capacity
154
Hole-Punching Prohibited Areas
155
Double-Feed Detection Conditions
156
9 Scanner Specification
160
Basic Specifications
161
Installation Specifications
163
External Dimensions
165
Glossary of Terms
166
Double Feed Detection
167
Dropout Color
167
Image Emphasis
169
Image Processing
169
Mirror Image
170
Noise Removal
171
Paper Jam
171
Read Operation
172
Temporary Error
172
Index
174
Other manuals for Fujitsu FI-4120C
Installation Procedures
9 pages
Brochure & Specs
2 pages
Instruction Manual
13 pages
Cleaning And Maintenance
66 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Fujitsu FI-4120C and is the answer not in the manual?
