69
- ExpressCards®/Smart Cards
Figure 26. Installing/Removing ExpressCards
See your ExpressCard manual for instructions on the installation of your card. Some cards may require that your
notebook is off while installing them.
To install an ExpressCard, follow these steps:
1 Make sure there is no ExpressCard currently in the slot. If there is, see See “Removing ExpressCards” on page 70.
2 If the eject button is extended, press it in until it clicks.
3 Insert your ExpressCard into the slot with the product label facing up. If you are inserting a 34 mm card, be sure
to align it with the left side of the slot when inserting it.
4 Push the card firmly into the slot until it is seated in the connector.
YOU MAY BE REQUIRED TO LOG ON AS ADMINISTRATOR OR A MEMBER OF THE ADMINISTRATOR’S GROUP TO COMPLETE THIS PROCEDURE. IF YOUR
COMPUTER IS CONNECTED TO A NETWORK, NETWORK POLICY SETTINGS MAY ALSO PREVENT YOU FROM COMPLETING THIS PROCEDURE.
Eject Button
ExpressCard Slot
34 mm ExpressCard
54 mm ExpressCard
