Fujitsu Lifebook S761 - Detaching Port Replicator

88 -
Detaching Port Replicator
To detach the Port Replicator:
1 Pull the Port Replicator’s release latch away from the Port Replicator to release it from your notebook.
(Figure 42)
2 Lift the notebook away from the Port Replicator to detach it. (Figure 43)
Figure 42. Unlatching the Port Replicator Figure 43. Removing the System
Release Latch
