Fujitsu PRIMERGY BX900 - Other Access Gateway Defaults; Processor and Memory Specifications; Weight and Physical Dimensions

42 Brocade 5450 Hardware Reference Manual
53-1001266-02
Processor and memory specifications
A
Other Access Gateway defaults
Table 7 shows the default settings for Access Gateway features.
Processor and memory specifications
The processor and memory installed in the Embedded Switch Module are shown in Table 8.
Weight and physical dimensions
Table 9 lists the weight and physical dimensions of the Embedded Switch Module.
TABLE 7 Access Gateway defaults
Feature Default setting
Automatic Failover Enabled on all N_ports
Automatic Failback Enabled on all N_ports
APC policy Disabled
Group policy Enabled
ADS policy Disabled
TABLE 8 Memory specifications
Memory Type Value
PowerPC 440EPX processor 667 MHz
SDRAM 512 MB DDR2 - for system memory at
64 bits wide with 8 ECC bits at 166
MHz.
Boot flash 4 MB - used during system boot only
and is field upgradable with password
protection.
Compact flash 512 MB - used for firmware
downloading and logging.
TABLE 9 Embedded Switch Module specifications
Dimension Measurements
Height 27.94 mm (1.1 in)
Width 192.84 mm (7.5921 in)
Depth 275.34 mm (10.8402 in)
Weight 1.31 kg (2.9 lbs) - without media
