INDOOR UNIT
FLOOR / CEILING
ABYG14LVTA
ABYG18LVTA
Kit (Flap base)
97
34
39
37
37
33
33
31
38
32
35
36
35 Louver 9358561027
36 Bushing B 9358554005
39 Motor Rod 9358560013
33 Protect Cover 9358564011
34 Support Stay 9358599006
37 Louver Stopper 9358555002
38 Louver Rod 9358559017
32 Flap Base 9358537022
31 Kit (Flap Base) 9372670040
Ref. Description Part number
2010.10.13
