INDOOR UNIT
SLIM DUCT
ARYG18LLTA
(Serial number : R)
774
174
850
934
100 x 8 = 800
30
377
78
55
10
620
864
900
198
168
151
78
55
Drain hose I.D. 3/4 in. , O.D. 1-1/16 in.
Unit : mm
2012.02.28 add
