FULGOR F7IT30 - Page 12

EN
8
In some cooking areas an internal diameter is indicated with
a lighter outline.
A
B
C
D
30” Wide Cooktop. Use the minimum size pan shown for
each cooking element.
Diameter pan size 30”
A
5” ¾ (14.5 cm) minimum diameter pan size
B
7” (18.0 cm) minimum diameter pan size
C
5” ¾ (14.5 cm) minimum diameter pan size
D
4” ¾ (12.0 cm) minimum diameter pan size
E
C
B
D
A
36” Wide Cooktop. Use the minimum size pan shown for
each cooking element..
Diameter pan size 36”
A
5” ¾ (14.5 cm) minimum diameter pan size
B
4” ¾ (12.0 cm) minimum diameter pan size
C
5” ¾ (14.5 cm) minimum diameter pan size
D
5” ¾ (14.5 cm) minimum diameter pan size
E
7” (18.0 cm) minimum diameter pan size
