Since the interference affects both cores equally, by subtracting the phase-shifted signals, the
interfering signal is completely neutralized. The result is a pure signal without any noise inter‐
ference.
1 Signal (left)
2 Signal (right)
3 Ground, shielding
Three-pole 1/8" mini phone jack
(stereo, unbalanced)
Plug and connection assignment
PL 108 A / 110 A / 112 A / 115 A
