Fungoo FLUPPI - Page 26

FLUPPI
26
38
37
Zgodne z normą PN-EN 71 stosuj zalecenia producenta odnośnie odległości oraz metody mocowania poszczególnych elementów
26
FLUPPI
In compliance with the standard PN-EN 71, apply guidelines of the producer in relation to distances and methods of fastening individual elements
16
15
2.1.
2.1.
W40 x50
↓16mm
Ø5,5 x50
W40 x56
↓16mm
Ø5,5 x56
FI 5,5
FI 5,5
21 1,6x9,0x62,8cm
x10
26a 1,6x9,0x34,0cm
x2
25a 1,6x9,0x44,0cm
x2
23a 1,6x9,0x56,5cm
x2
19a 1,6x9,0x68,5cm
x2
17a 1,6x9,0x80,5cm
x2
16a 1,6x9,0x92,5cm
x2
15a 1,6x9,0x105,0cm
x2
