FLUPPI
8
02
01
Zgodne z normą PN-EN 71 stosuj zalecenia producenta odnośnie odległości oraz metody mocowania poszczególnych elementów
8
FLUPPI
In compliance with the standard PN-EN 71, apply guidelines of the producer in relation to distances and methods of fastening individual elements
x2 !!
1260
1260
a = a
1260
a = a
1260
1. 2.
T80
W80
OS1
T80 x4*2 = 8
OS1 x4*2 = 8
W80 x12*2 = 24
↓80mm
Ø5,5 x4
1. 2.
↓80mm
Ø5,5 x4
OS1 x2
W80 x12
T80 x4
OS1
T80
W80
T80
W80
OS1
OS1
T80
W80
FI 5,5
!
FI 5,5
1 7,0x7,0x230cm
x2*2 = 4
18 1,6x9,0x80cm
x3*2 = 6
18 1,6x9,0x80cm
x3
2 7,0x7,0x185cm
x2
