Fungoo GX PLUTO - Page 10

10
GX_PLUTO
02
01
ŐŽĚŶĞnjŶŽƌŵČWEͲEϳϭƐƚŽƐƵũnjĂůĞĐĞŶŝĂƉƌŽĚƵĐĞŶƚĂŽĚŶŽƑŶŝĞŽĚůĞŐųŽƑĐŝŽƌĂnjŵĞƚŽĚLJŵŽĐŽǁĂŶŝĂƉŽƐnjĐnjĞŐſůŶLJĐŚĞůĞŵĞŶƚſǁ
10
In compliance with the standard PN-EN 71, apply guidelines of the producer in relation to distances and methods of fastening individual elements
230 230
1594
1594
1594
1594
1. 2.
W80 x16
՝H58
Ø5,5 x16
1. 2.
W80 x8
՝H58
Ø5,5 x8
FI 5,5
FI 5,5
H-1 3,2x5,8x113cm
x2
H-2 3,2x5,8x106cm
x2
H-1 3,2x5,8x113cm
x2
H-3 3,2x5,8x104cm
x2
H-2 3,2x5,8x106cm
x2
