Fungoo GX PLUTO - Page 33

33
GX_PLUTO
ŐŽĚŶĞnjŶŽƌŵČWEͲEϳϭƐƚŽƐƵũnjĂůĞĐĞŶŝĂƉƌŽĚƵĐĞŶƚĂŽĚŶŽƑŶŝĞŽĚůĞŐųŽƑĐŝŽƌĂnjŵĞƚŽĚLJŵŽĐŽǁĂŶŝĂƉŽƐnjĐnjĞŐſůŶLJĐŚĞůĞŵĞŶƚſǁ
47
48
33
In compliance with the standard PN-EN 71, apply guidelines of the producer in relation to distances and methods of fastening individual elements
T80 x2
T60 x4
P17
T60
T80
SF x2
M10 x4
min
35 cm
min
35 cm
min
30 cm
min
45 cm
min
30 cm
P17 x6
