SPECIFICATIONS OF THE ECHO SOUNDER LS-6100
1. GENERAL
1.1 TX Frequency 50 kHz or 200 kHz, 50/200 kHz dual transmitting selectable
1.2 Transmit Method Single or dual transmitting
1.3 Output Power 300 Wrms
1.4 TX Rate Max. 550 pulse/min
1.5 Pulse-length 0.1 to 1.0 ms
1.6 Sensitivity 10 dBµV
2. DISPLAY UNIT
2.1 Display system 6-inch monochrome LCD, 92 mm (W) x 122 mm (H), 240 x 320 dots
2.2 Display Mode Single frequency (high/low freq.), Dual-frequency, Zoom, Nav data-1/2
Marker zoom, Bottom zoom, Bottom-lock
2.3 Display Range
Range Setting Range
1 2 3 4 5 6 7 8
Display
range
Meter 5 10 20 40 80 150 200 300 2-500
Feet 15 30 60 120 200 400 600 1000 7-1500
Fathoms 3 5 10 20 40 80 100 150 1-250
Passi/Braza 3 5 10 30 50 100 150 200 1-300
2.4 Range Shift 0-500 m, 0-1500 ft, 0-250 fa, 0-300 p/b
2.5 Expansion Range Bottom-lock expansion: 3 to 10 m
Sectional expansion: 2 to 50 m
2.6 Display Advance Speed 8 steps (Lines/TX; Freeze, 1/16,1/8,1/4,1/2,1/1,2/1, 4/1)
2.7 Function Settings Noise limit, Clutter, Signal level, Shift, A-scope, Deep gain
Automatic bottom tracking, White line, Hue, Advance speed
3. INTERFACE
3.1 Input data sentences IEC61162-1/NMEA0183 Ver 1.5/2.0/3.0
GGA, RMA, RMB, RMC, BWC, GLL, HDT, HDG, VTG, VHW, MTW,
MWV, MDA, XTE
3.2 Output data sentences IEC61162-1/NMEA0183 Ver 1.5/2.0/3.0, interval: 2 s
MTW*, VHW*, DBT, DPT, RMB*, TLL* by key operating
*: External data required
4. POWER SUPPLY 12 VDC: 0.8 A
5. ENVIRONMENTAL CONDITION
5.1 Ambient Temperature Display unit: -15°C to +55°C
5.2 Damp Heat 93% or less at 40°C
5.3 Water proofing IPX5
6. COATING COLOR N3.0
