• Adjustable charge rates.
• Reverse Polarity Protection on Output.
• Delta Peak cut-off.
• Connect the required battery charge leads to the charger by
clamping the bare ends of the lead into the output. Please
ensure correct polarity (+ = red, - = black).
• Connect either the mains or 12V input power lead into the
relevant socket on the back of the charger and connect this
power lead to the appropriate power source.
• Select the correct charge rate for the battery pack being
charged.
• Connect the battery to be charged to the output. When
connected, the Red LED will glow to indicate fast charging.
• When the battery is fully charged, the peak circuitry will
terminate the fast charge and the Green LED will glow to
indicate that the battery is now fully charged.
The charging time for a discharged pack can be calculated by:-
Time (hours) = Battery Capacity (mAh) / Change Rate (mA) x 1.2
• Do not charge packs that cannot accept fast charging at
the selected rate.
• Always monitor the battery pack being charged and
disconnect from the charger if the pack becomes
excessively hot.
• NEVER leave the charger unattended whilst charging.
• DO NOT fast charge batteries immediately after use while
they are still warm. Allow to cool to ambient temperature
before charging.
