31
•If you set a condition switch channel, using the AFR function on that channel set a flat point
curve for each flight condition. Then you can utilize all 5 flights conditions.
Set the point curve with AFR for each flight condition of the transmitter.
Switch Channel Rate
Neutral
Cond1
Cond3
Cond5Cond4Cond2
-100% 100%-25%-75% 75%25%0%
-100%
100%
0%
3. Battery voltage
Displays the voltage of the receiver battery connected to CGY760R.
4. Gyro operation mode / Gyro gain
Displays "AVCS" or "Normal" operation mode and gyro gain of aileron (roll), elevator (pitch)
and rudder (yaw) axis.
5. Roll and Elevator rate maximum display
This screen displays the maximum roll rate and maximum elevator rate recorded during
flight. Data is reset when the power is turned off. If you want to check the maximum rate,
leave the power on after flight. Use the [
/
+] or [
/
-] key to move the cursor to each rate
display and press and hold [Enter] key to reset the display.
6. Governor ON / OFF
Indicates the ON / OFF switch status of the governor function. When "ON" is displayed,
the governor function is activated.
