62
(5) RPM set.: RPM setting
Setting the main rotor RPM. This is calculated by engine revolution with
the gear ratio of the main shaft.
When the rotation speed can be set with the governor mixing function
of the transmitter, it is necessary to first match the display rpm value of
1-2-3 of "RPM Set" with the display rpm value of the transmitter.
Setting ranges: off / 700 ~ 4,000 rpm Initial value: 1,000 rpm
*To set lower than 1,000 rpm, set "Low. Revo" (page 90) of "GOV. EXPERT"
menu to 700 rpm.
(6) Stick sw.: Stick switch
The governor can be activated by throttle stick position. Move the cursor
to "Stick sw" by pressing the
[
/+] or [ /-] key and press the [Enter] key
to enter the setting mode. "EXECUTE: Enter (1sec)" is displayed. Move
the throttle stick to the desired governor on position. Press the [Enter]
key for about 1 second, , memorizing that point.
This stick switch function is always enabled when the next "ON/OFF sw"
is "INH" or the "Governor ON / OFF switch is not set by S.BUS setting.
When governor is turned on and off by transmitter throttle stick
The data is set so that the governor can be
turned on and off with the transmitter throttle
stick position. The following describes this
operation.
• Throttle stick over set point and more than
60% of set rotation speed.
ON
*This is the setting value of "(9) Gov. On.
Revo: Governor ON revolution setting" on
page 89.
• Throttle stick held at the set point or more
Remains.
ON
• Throttle stick position is below the set point
selected.
OFF
When idle up
• When the throttle curve is set at idle up, and when the throttle output is over
the set value (initial value: 30%), the governor will always and remain ON even
if the stick is lowered to the bottom.
(OFF at slow side)
Set point or less
0%
100%
(Governor operating point)
Set speed
The stick is at, or beyond
the set point and is 60%
of the rotation speed
value of the governor.
To Next Page
