Future light SC-780 - Page 9

9
29.3.1998
List of materials for
PCB SC-780 V.1
Document No.:
1/3
POS. ARTICAL TYPE DESCRIPTION Q'TY
SPARE PARTS
No.
1IC1
PIC 16C57 HS/P MICROCONTROLLER 4
2IC2
3IC3
4IC4
5 IC5 SN75176 INTERCHANGE CIRCUIT 1
6IC6
L293D MOTOR DRIVER 6
7IC7
8IC8
9IC9
10 IC10
11 IC11
12 IC12 74HC04 6xINVERTOR 1
13 IC13
L293D MOTOR DRIVER 314 IC14
15 IC15
16 IC16 74HC04 6xINVERTOR 1
17 IC17
L293D MOTOR DRIVER 318 IC18
19 IC19
20 IC20 74HC04 6xINVERTOR 1
21 IC21 LM7805 INTEGRATED VOLTAGE REGULATOR 1
22 T1 BC807-40 TRANSISTOR PNP SMD 1
23 T2 BC817-40 TRANSISTOR NPN SMD 1
24 T3 BD135 TRANSISTOR NPN 1
25 D1 BZX 55/7V5 VOLTAGE REGULATOR DIODE SMD 1
26 D2
LL4148 DIODE SMD 2
27 D3
28 D5
SM4007 RECTIFIER DIODE SMD 8
29 D6
30 D7
31 D8
32 D9
33 D10
34 D11
35 D12
36 D13 L-53GR LED DIODE 1
37 D14
P600B BRIDGE RECTIFIER 8
38 D15
39 D16
40 D17
41 D18
42 D19
43 D20
44 D21
45 R1 1K RESISTOR CP1206 SMD 1
46 R2 4K7 RESISTOR CP1206 SMD 1
47 R3 15R RESISTOR CP1206 SMD 1
48 R4 1K RESISTOR CP1206 SMD 1
