- 15 -
distribution.
Blade Inspection
z Tilt the lawn mower to the right, so the air cleaner side is up. This will help to prevent fuel leakage and
hard starting.
z Inspect the blade for damage, cracks and excessive rust or corrosion.
A dull blade can be sharpened, but a blade that is excessively worn, bent, cracked, or otherwise
damaged must be replaced.
z A torque wrench must always be used when installing the blade.
Check that the blade bolts are tight.
Removal and installation
If you remove the blade for sharpening or replacement, you will need a torque wrench for installation.
Wear heavy gloves to protect your hands.
z Remove the bolt with a socket wrench. Use a wooden block to prevent the blade from turning when
removing the bolt. Then remove the blade.
z Install the blade using the blade bolt and special washers. Be sure to install the special washers with
the concave side toward the blade and the convex side toward the bolt.
z Tighten the blade bolt with a torque wrench. Use a wooden block to prevent the blade from turning
when tightening the bolt
Grass catcher cleaning and replacement
- Cleaning
Wash the bag with a garden hose, and allow it to dry completely before use; a wet bag will clog quickly.
- Replacement
z Unclip the plastic edges of the bag from the frame; remove the frame from the bag.
z Insert the frame into the bag; clip the plastic edges of the bag onto the frame.
