FXA 501741208 - PART LIST

- 22 -
10. PART LIST
Pos.
No.
Part No.
Description
Specification
Remark
Qty.
A
Part A
A-1
G3376000001
Clutch Lever
Q235
Ø7.8mm
1
A-2
G3353000001
Brake Lever
Q235
Ø7.5mm
1
A-3
G3XW0000000
Limiting Stopper
PA66
1
A-4
G3320000000
Foam Pipe
NBR
20x510x3mm
1
A-5
G333F000001
Upper Handle
Q235
Ø22/t=1.35
1
A-6
B2011B00000
Nut
M6
2
A-7
G339X300000
Cable Fixing Clamp
PA66+GAF
1
A-8
G339XX60000
Brake Cable
G339XX60000
1
A-9
G339XYA0000
Clutch Cable
G339XYA0000
1
A-10
B1066W06032
Bolt
M6x32
1
A-11
G33B4000001
Lower Handle
Q235
Ø22/t=1.35
1
A-12
B1088W08050
Bolt
M8x50
4
A-13
B5019W00000
Flat Washer
Ø8.5xØ16x1.5mm
4
A-14
G33C1100010
Knob
PP
4
A-15
B2020W00000
Nut
M8
M8
4
A-16
G33K0000000
Rope Guide
Q235
Ø6mm
1
A-17
G33H0000000
Cable Support
PP
2
A-18
B1087W08032
Bolt
M8x35
2
A-19
B2009W00000
Nut
M8
2
A-20
G33J0000000
Handle Plug
PP
2
B
Part B
B-1
Y2P50000010
Y139V Engine
1
B-2
B1077W08025
Bolt
M8x25
3
B-3
G34AW300000
Belt Wheel
Q235
1
B-4
BE001W00000
Flat Key
#45
1
B-5
G3530000000
Blade adapter
Q235
1
B-6
G22K0000000
Screw Cap
PVC
2
B-7
G3230000000
Belt Cover
PP
1
B-8
B3022W00000
Screw
ST4.8x12-F-H
2
B-9
G3510000000
18" Blade
40Mn
B/t=3.0mm
1
B-10
G3520000000
Blade Washer
65Mn
t=3
1
B-11
B1001B00032
Blade Bolt
20Cr
3/8-24UNF-2Bx32
1
C
Part C
C-1
B1036W08015
Bolt
M8x15
4
C-2
G34BD000000
Height Adjustment Plate
Q235
G46H
1
C-3
G32B0000000
Right Bracket
Q235
t=3
1
C-4
B2009W00000
Nut
M8
4
C-5
G3217Y00001
Deck
ST1.35
1
