FXA 501741208 - Brake cable setup; Panel Setup; Grass Bag Assembly

- 7 -
Brake cable setup
Put the brake cable and clutch cable to the hole of brake lever and clutch lever. (see the arrow mark)
Panel Setup
Take out the panel and two screws in a bag from carton and fix the panel with the screws.
* Note: Not all models do have middle Panel. (Only for G53SHL-C)
Grass Bag Assembly
z Slide the grass bag frame into the grass bag and attach the clips as shown.
CLUTCH CABLE
BRAKE CABLE
SCREW
CONTROL PANEL
