3. TECHNICAL DATA
Model
501741209 / G46SHL-E
Engine type
BS450E OHV
Self-Propelled
Yes
Engine Displacement
125 cm
3
Nominal Power
1.7 kW
Blade Width
457 mm
Rated Speed
2800/min
Gasoline Tank Capacity
0.80 L
Grass catcher capacity
65 L
Net Weight
31.70 kg
Height adjustment
25-75 mm, 6 adjustment
GuaranteedSoundpressurelevelattheoperator’s
position
(According to EN ISO 5395-1
Annex F & EN ISO 5395-2, EN ISO 4871)
83.10 dB (A)
K=2.50 dB
Measured sound power level
Guaranteed Sound Power level
(According to 2000/14/EC)
94.36 dB(A) – K=1.23 dB
96 dB(A)
Vibration
(According to EN ISO 5395-1
Annex G & EN ISO 5395-2)
6.360 m/s²
K=1.5 m/s²
4. BEFORE OPERATION
Engine Oil
The lawn mower is shipped without oil in the engine.
All engines are run at the factory prior to packaging. Most of the oil is removed prior to shipment; however,
some oil remains in the engine. The amount of oil left in the engine varies.
Add enough oil to bring the oil level between the upper and lower limit marks on the dipstick as shown. Do
not overfill engine with oil.
A: Oil filler cap/dipstick
B: Upper limit / Lower limit
C: Oil tank inlet
