GUIDE BAR
The guide bar is subjected to especially severe wear
and tear at the nose and the bottom. To avoid one-
sided wear and tear, turn the guide bar over every
time you sharpen the chain.
1. When you have finished working, clean out the
groove and the oil passages, with a special
scraping hook. (Fig.23).
2. Periodically trim the sides of the rails using a
flat file. If not done in the long run the
“feathered edges” might break away and
damage the bar. (Fig.24)
3. If one rail is highe
r than the other one, it is
necessary to make it even with a flat file and
then smooth them with a file or fine grain
abrasive paper. (Fig.25)
CHAIN TENSION
Check the chain tension frequently and adjust as often
as necessary to keep the chain snug on the bar, if the
chain is pulled down with the fingers at the centre of
the bar the gap between the chain and the bar should
be 3 to 4mm.
NEW CHAINS
A new chain will need to be readjusted after as few as
5 cuts. This is normal during the break in peri
od, future
adjustments will be required less often.
OIL PASSAGES
Oil passages on the bar should be cleaned to
ensure proper lubrication of the bar and chain
during operation.
NOTE. The condition of the oil passages can be easily
checked. If the passages are clear, the chain will
automatically give off a spray of oil within seconds of
starting the saw. Your saw is equipped
with an
automatic oiler system.
STORAGE
Remove the batteries and store in a secure location
out of the reach
of children.
Before storage, wipe any dirt or debris from the
battery area.
Clean all foreign material from the product. Store idle
unit indoors in a dry, well-ventilated area that is
inaccessible to children. Keep away from corrosive
agents such as garden chemicals and de-icing salts.
Always place the blade guard on the chain saw blade
when transporting or storing the chainsaw. The blade
guard is a snug fit and must be attached very carefully
due to the sharp teeth on the saw c
hain. This is best
done by grasping the blade guard at one end, in the
centre portion of the guard, and carefully sliding it
over the chain. Use caution to avoid the sharp teeth of
the chain.
NOTE: The saw chain is very sharp. Always wear
protective gloves when handling the chain.
TECHNICAL SPECIFICATION
Voltage 2x18V DC
Use 2 x 18V battery
packs of equal
capacity and power
No load speed 4500min
-1
Cutting length 345mm
Chain brake < 0.12s
Chain bar length 355mm
Chain speed 8.5m/s
Oil tank capacity 150ml
Sound Pressure Level L
pA
85.65dB(A)
k=3dB(A
Sound Power Level L
WA
96.65dB(A)
k=2.6dB(A
Vibration Level 4.379m/s
2
K=1.5m/s
2
