FYTTER Runner RU-3BX - Page 31

FYTTER |WWW.FYTTER.COM
PAG- 30
No.
Desc.
Spec.
Qty
Remark
r
No.
Desc.
Spec.
Qty
Remark
r
1
Front base
1
41
Incline adjustor
143*65*35
2
2
Main frame
1
42
Belt
184 J6
1
3
Uprights
2
43
Silicone cushion
100*30*28
2
4
Console frame
1
44
Cushion
30*23*14
6
5
Runningboard
reinforcement tube
1
45
Transport wheel
￠
45*21*
￠
8.5
2
6
Front roller
1
46
Handrail plug
Φ32
2
7
Rear roller
1
47
Power cord buckle
6p-4
1
8
Cylinder
1
48
Ring retaining wire
plug
￠
24*
￠
18*6
1
9
Hexagon head bolt
M10*105
2
49
Round head steel ball
latch
￠
27*
￠
10
2
10
Hexagon head bolt
M8*45
6
50
Adjustment foot pad
φ28*M8*15
4
11
Hexagon head bolt
M8*40
3
51
Handrail cover
￠
30*T5*250
2
12
Hexagon head bolt
M8*25
1
52
Console
1
13
Hexagon head bolt
M8*15
4
53
Display overlay decal
1
14
Hexagon cylindrical head
bolt
head boltcylindrical head
bolt
M8*15
4
54
Controller board
1
15
Hexagon cylindrical head
bolt
M8*12
4
55
Upper cable of console
1
16
Hexagon cylindrical head
bolt
M8*60
3
56
lower cable of console
1
17
Outer hexagonal bolt
M8*75 (25thread)
1
57
Emergency stop key
set
1
18
Hexagon countersunk
head bolt
M6*28
8
58
Emergency stop key
sensor
1
19
Cross recessed large flat
head screw
M5*10
4
59
Pulse sensor set-Right
1
20
Self-drilling screw
ST4*20
2
60
Pulse sensor set-Left
1
21
Cross recessed head
tapping screw
ST4*12
20
61
DC motor
1
22
Cross recessed round
head tapping screw
ST4*15
12
62
Power cable
1
23
Cross recessed round
head tapping screw
ST2.2*8
6
63
Rocker switch
1
24
Flat Washers
Φ10*1.2
2
64
Overload protector
1
25
Flat Washers
Φ8*1.2
6
65
Blue single branch wire
1
26
Internal serrated lock
washer
Φ8*1.2
15
66
Brown single branch
wire
1
27
Lock nut
M8
8
67
Brown single branch
wire
1
28
Standard spring washer
Φ8
6
68
Blue single branch wire
1
29
Motor cover
568*352*110
1
69
Ground wire
1
30
Bottom cover
540*318*21
1
70
Silicone oil
1
31
Rear protect corner-Right
116*94*82
1
71
Magnetic ring
1
32
Rear protect corner-Left
corner-Left
116*94*82
1
72
Hexagon wrench
5#
1
33
Upright-cover-Right
200*140*65
1
73
Hexagon wrench
6#
1
