FYTTER TR-6SX - Page 27

26
NO.
NAME
QTY.
NO.
NAME
QTY.
1
Main frame
1
42
magnet plate
1
2
Rear stabilizer
1
43
flat washer
13
3
Front stabilizer
1
44
revolving shaft
1
4
Seat sliding set
1
45
circlip
4
5
Seat
1
46
screw
2
6
Pulley
3
47
Flywheel axle
1
7
Sliding rail
1
48
Bearing
2
8
Handle bar
1
49
Screw
7
9
Console
1
50
Nut
6
10
Knob
1
51
Guide pulley sleeve
4
11
Pedal
1
52
Belt guide pulley
2
12
tube plug left-front stabilizer
1
53
M10*1.5 Bolt
2
13
Adjusting tube plug-rear stabilizer
2
54
M10*1.5 Pedal pole
1
14
Console wire
2
55
Washer
1
15
screw
2
56
Adjusting foot pad
1
16
sensor fixed base
1
57
M8*1.25 bolt
3
17
adapter
1
58
spacer sleeve
6
18
Sensor wire
2
59
Bearing
6
19
Pedal support tube
1
60
M8 nylon nut
3
20
Tube plug
4
61
bolt
2
21
Curved washer
2
62
M8 bolt
2
22
bolt
2
63
Tube plug
1
23
flywheel
1
64
M8 nut
2
24
cover-left
1
65
plug
1
25
cover-right
1
66
M10X1.5bolt
1
26
handle bar foam
2
67
Bolt
1
27
spring case
1
68
Screw
8
28
crash pad
5
69
Spring washer
4
