2.1 General Overview
2.2 Product Selection Buttons
General Description of Ruby
2.
1- Hot Water Tap
2- Product Selection Buttons
4 - Water Tank
3- Steam Tap
5 - Power Switch
6 - Steam Arm
8 - Drip Tray
7 - Feet
9 - Drain Tray
10 - Boiler Pressure Gauge
12 - Hot Water Outlet
11 - Filter Holder
a - One Coffee
b - Continuous Coffee
c - Two Coffees
d - Boiler Water Level Indicator
Boiler
e - Tank Water Level Indicator
f - Heating Element Indicator
Water Supply
Internal Tank
Element Wattage
1.500 W (230 V)
Boiler Capacity
1.5 L
Tank Capacity
3 L
Water pump
Vibr. Pump 18 bar
1
2
3
10
4
5
6
7
8
Indicador nivel
9
12
11
B
C
A = 367 mm
B = 306 mm
C = 511 mm
A
a
b
c
Versión
Electrónica
d e f
Versión
Semiautomática
d f
b
e
18
