This diagram is only for 60Hz 240VAC. Verify line in voltage before connecting. If you are not sure of the operation
and/or installation of this unit, contact an electrician or contract our office. Galaxy Unlimited, LLC is not responsible
for incorrect field wiring, damages to equipment or harm to anyone or anything. Incorrect field wiring will void
warranty.
Important:
If the voltage on site does not match the voltage indicated in the Control box door, please call our technical support
team to receive further instructions.
Phone: 888-317-7203
Inside Motor Wiring:
Black: T1
Orange: T4
Red: T5
Join: T2, T3, T8
Inside Control Box Motor Wiring:
Orange: Motor Orange
Black: Motor Black
Red: Motor Red
Green: Tied together with Transformer green and Power green.
White: Not used in 240 Volt configuration.
*If your motor is causing your cables to spool backwards on the winder, swap Motor Black and Motor Orange to
reverse the rotation of the motor.
Power Disconnect Wiring:
Black: L1
White: L2
Green: Tied together with Transformer green and Motor Green
