Galaxy G8 - Page 14

14
PARTS LIST February 17, 2011, Rev. O
G8-Y, G12-Y 120V/240V/230CE
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description and Model Designation
MODEL
Part
Number
Key
Number
- 2M-Y8602 1 LABEL STRIPE YELLOW/BLUE (Not Shown) G12
- 2M-Y8420 1 LABEL STRIPE BLACK (Not Shown) G12
1 2M-Z9183 1 LABEL FRONT
2 2E-Z9310 2 SWITCH (LIGHTED) after serial number G8010126 G8
2E-Z9310 3 SWITCH (LIGHTED) before serial number G8010126 G8
2E-Z9310 2 SWITCH (LIGHTED) after serial number G1206539 G12
2E-Z9310 3 SWITCH (LIGHTED) before serial number G1206539 G12
3 C3-Y7952 1 BRACKET CATCH
4 2R-Y7844 2 CATCH MAGNETIC
5 C3-Y7953 1 COVER BRACKET
6 C3-Y7377 2 BRACKET HINGE LEFT
7 C3-Y7446 2 BRACKET HINGE RIGHT
8 C3-Y8187 1 LOWER DOOR
9 C3-Y7475 2 DOOR PULL ASSEMBLY (INC.IN DOOR ASSYS.)
10 C3-G8074 1 LEFT DOOR ASSEMBLY
11 C3-G8073 1 RIGHT DOOR ASSEMBLY
12 2L-Y8863 1 OIL MEASURE CUP 2 CUP (PLASTIC)
13 2L-Y8812 1 CORN MEASURE CUP 2 CUP (PLASTIC)
14 2L-Y4916 1 SCOOP - POPCORN (PLASTIC)
15 C3-G8021 1 CORD ASSEMBLY 120V G8
C3-G8022 1/1 CORD ASSEMBLY 240V G8 / G12
C3-G1410 1 CORD ASSEMBLY 120V G12
2E-Z0151 1/1 CORD ASSEMBLY 230CE G8 / G12
16 2K-Y2968 1 BUSHING-STRAIN RELIEF 120V G8
2K-Y6764 1 BUSHING 120V/240V G12
17 C3-Y7940 1 DRAWER CORN
18 2A-6904 4 FOOT
2P-Y3404 4 PLUG - FOOT
2C-1557 4 SCREW - FOOT
19 2E-Y2849 1 BLOCK TERMINAL
20 2P-6475 4 CLIP-TY
21 2N-Y8502 1 ELEMENT-80 WATT 120V
2N-Y8503 1 ELEMENT-90 WATT 240V/230CE
22 2K-Y1139 1 BUSHING HEYCO
23 2Q-Y7830 2 GLASS SIDE (TEMPERED)
24 2I-Y7836 6 CHANNEL GLASS (TOP/BOTTOM)
25 2I-Y7840 6 CHANNEL GLASS (UPRIGHT)
26 2Q-Y8606 1 GLASS FRONT
27 2E-Y8212 1 SOCKET LAMP
2E-Y9433 1 SOCKET LAMP 230CE
28 2S-8337 1 LAMP-150W 120V G8
2S-Y2238 1 LAMP - 250W 120V-120V G12
2S-Y8712 1/1 LAMP 150W 230CE/240V G8 / G12
2S-Y8346 1 LAMP 250W 240V G12
29 2B-Y7829 1 LAMP SHIELD
30 2C-1823 10 WASHER LOCK
31 2C-9398 4 SCREW
32 2E-T1042 1 RECEPTACLE 120V
2E-Z0089 1 OUTLET STRAIGHT BLADE 230CE/240V
33 2A-Y8645 1 PIN STOPPER-SHORT
34 2C-Y8646 1 SCREW
35 2A-Y8032 1 PIN STOPPER
36 2C-Y8147 1 SCREW
1
2
Star International Holdings, Inc. Company
