PARTS LIST November 22, 2010, Rev. O
G8-AT, G12-AT 120V/240V/230CE
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description and Model Designation
MODEL
Part
Number
Key
Number
1 2M-Z9184 1 LABEL FRONT
2 2E-Z9310 2 SWITCH (LIGHTED) after serial number G8010126 G8
2E-Z9310 3 SWITCH (LIGHTED) before serial number G8010126 G8
2E-Z9310 2 SWITCH (LIGHTED) after serial number G1206539 G12
2E-Z9310 3 SWITCH (LIGHTED) before serial number G1206539 G12
3 C3-Y7952 1 BRACKET CATCH
4 2R-Y7844 2 CATCH MAGNETIC
5 C3-Y7953 1 COVER BRACKET
6 C3-Y7377 2 BRACKET HINGE LEFT
7 C3-Y7446 2 BRACKET HINGE RIGHT
8 C3-Y8187 1 LOWER DOOR
9 C3-Y7475 2 DOOR PULL ASSY. (INC. IN DOOR ASSYS.)
10 C3-G8076 1 LEFT DOOR ASSY.
11 C3-G8075 1 RIGHT DOOR ASSY.
12 2L-Y8863 1 OIL MEASURE CUP 2 CUP (PLASTIC)
13 2L-Y8812 1 CORN MEASURE CUP 2 CUP (PLASTIC)
14 2L-Y4916 1 SCOOP - POPCORN (PLASTIC)
15 C3-G8021 1 CORD ASSY. 120V G8-AT, G8-Y
D5-HFD028 1 CORDSET ASSY. 5-20P,6' G8-AT-120VC, G8-Y-120VC
C3-G1410 1 CORD ASSY. 120V G12-AT
C3-G8022 1/1 CORD ASSY. 240V G8-AT / G12-AT
2E-Z0151 1/1 CORD ASSY 230CE G8-AT / G12-AT
16 2K-Y2968 1 BUSHING - STRAIN RELIEF 120V/240V
2K-Y6764 1 BUSHING 120V/240V G12-AT
17 C3-Y7940 1 DRAWER CORN
18 2A-6904 4 FOOT
2P-Y3404 4 PLUG - FOOT
2C-1557 4 SCREW - FOOT
19 2E-Y2849 1 BLOCK TERMINAL
20 2P-6475 4 CLIP-TY
21 2N-Y8502 1 ELEMENT - 80 WATT 120V
2N-Y8503 1 ELEMENT - 90 WATT 240V
22 2K-Y1139 1 BUSHING HEYCO
23 2Q-Y8508 3 GLASS TEMPERED
24 2I-Y7836 6 CHANNEL GLASS
25 2I-Y7840 6 CHANNEL GLASS
26 2E-Y8212 1 SOCKET LAMP
2E-Y9433 1 SOCKET LAMP 240V
27 2S-8337 1 LAMP - 150 WATT 120V G8-AT
2S-Y2238 1 LAMP - 250 WATT 120V G12-AT
2S-Y8712 1/1 LAMP - 150 WATT 230CE/240V G8-AT / G12-AT
2S-Y8346 1 LAMP 250W 240V G12-AT
28 2B-Y7829 1 LAMP SHIELD
29 2C-1823 10 WASHER LOCK
30 2C-9398 4 SCREW
31 2E-T1042 1 RECEPTACLE 120V
2E-Z0089 1 RECEPTACLE, STRAIGHT BLADE 230CE/240V
32 2A-Y8645 1 PIN STOPPER - SHORT
33 2C-Y8646 1 SCREW
34 2A-Y8032 1 PIN STOPPER
35 2C-Y8147 1 SCREW
