PARTS LIST November 22, 2010, Rev. O
G8 EIGHT OUNCE KETTLE 120V/240V/230CE
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description
MODEL
Part
Number
Key
Number
- C3-G8098 1 KETTLE ASSEMBLY COMPLETE 120V
- C3-G8095 1 KETTLE ASSEMBLY COMPLETE 230CE/240V
1 2P-8354 1 CAP-TWIST LOCK 120V
2P-Z0017 1 PLUG , STRAIGHT BLADE 230CE/240V
2 2K-3831 2 BUSHING
3 2E-Y8063 1 CONDUIT
4 2E-1177 1 CONNECTOR
5 2E-Y4967 1 WASHER
6 2E-Z10325 1 WIRE #11, WIRE KIT ASSEMBLY 120V
2E-Z10459 2 WIRE #11, WIRE KIT ASSEMBLY 230CE/240V
7 2E-Z10325 1 WIRE #12, WIRE KIT ASSEMBLY 120V
8 2E-Z10325 1 WIRE # 18 (GND), WIRE KIT ASSEMBLY 120V
C3-G8045 1 WIRE #18, (GND), WIRE KIT ASSEMBLY 230CE/240V
9 C3-G8030 1 SHELL ASSEMBLY, 8 OZ.
10 2C-2559 3 NUT-ACORN
11 2R-Y8892 1 HANDLE
12 2P-Y8092 1 RETAINING RING
13 2C-Y9767 2 WASHER
14 2P-Y8061 1 SPRING
15 2A-Y8891 1 ROD-CATCH
16 2A-Y8022 1 SET SCREW
17 2A-Y8051 2 STOPPER
18 2C-H8670 4 WASHER-LOCK
19 2C-1493 4 SCREW
20 C3-Y7886-1 1 CHANNEL-RUBBER
21 2C-2560 7 NUT
22 2C-1827 11 EXT. WASHER
23 C3-Y8043 3 CLAMP
24 C3-Y8042 1 THERMOSTAT CLAMP
25 C3-Z5624 1 LUG GB 120V
2E-Z10326 1 WIRE #17, WIRE KIT ASSEMBLY 120V
2E-Z10459 2 WIRE #17, WIRE KIT ASSEMBLY 230CE/240V
26 2T-6213 1 THERMOSTAT 120V (#G8008925 & BELOW)
2T-Y7422 1 THERMOSTAT 120V (#G8008926 & ABOVE)
2T-Y9453 1 THERMOSTAT 230CE/240V (#G8008961 & ABOVE)
27 2N-Y5592 1 ELEMENT HEATING 1420 WATT 120V
2N-Y5593 1 ELEMENT HEATING 1420 WATT 230CE/240V
28 2A-Y8027 1 SPACER-LONG
29 2A-Y8028 2 SPACER
30 2F-Z0019 1 PLATE-KETTLE
31 C3-G8029-PS 1 KETTLE LINER ASSEMBLY, STUDS
32 PS-G1499 1 HIGH LIMIT THERMOSTAT REPLACMENT KIT 120V
2T-Z10182 1 HIGH LIMIT THERMOSTAT, manufactured after Aug. 2007 120V/230CE/240V
33 2C-Z0006 1 SCREW
34 2C-2556 1 NUT
35 2C-1825 1 LOCKWASHER
NI C3-Z5637 3/4 SLEEVING 4.5", WIRE 120V/240V
1
1
