- C3-G1201 1 KETTLE ASSEMBLY COMPLETE 120V
- C3-G8096 1 KETTLE ASSEMBLY COMPLETE 230CE/240V
1 2P-8354 1 CAP-TWIST LOCK 120V
2P-Z0017 1 PLUG, STRAIGHT BLADE 230CE/240V
2 2K-3831 2 BUSHING
3 C3-Y8063 1 CONDUIT
4 2E-1177 1 CONNECTOR
5 2E-Y4967 1 WASHER
6 2E-Z10326 1 WIRE # 11, WIRE KIT ASSEMBLY 120V
2E-Z10460 1 WIRE # 11, WIRE KIT ASSEMBLY 230CE/240V
7 2E-Z10326 1 WIRE #12, WIRE KIT ASSEMLBY 120V
2E-Z10460 1 WIRE #12, WIRE KIT ASSEMLBY 230CE/240V
8 2E-Z10326 1 WIRE (GND), WIRE KIT ASSEMBLY 120V
2E-Z10460 1 WIRE (GND), WIRE KIT ASSEMBLY 230CE/240V
9 C3-G8030 1 SHELL ASSEMBLY, 8 OZ.
10 2C-2559 3 NUT-ACORN
11 2R-Y8892 1 HANDLE
12 2P-Y8092 1 RETAINING RING
13 2C-Y9767 2 WASHER
14 2P-Y8061 1 SPRING
15 2A-Y8891 1 ROD-CATCH
16 2A-Y8022 1 SET SCREW
17 2A-Y8051 2 STOPPER
18 2C-H8670 4 WASHER
19 2C-1493 4 SCREW
20 C3-Y7886-1 1 CHANNEL RUBBER
21 2C-2560 8 NUT
22 2C-1827 10 EXT. WASHER
23 C3-Y8043 3 CLAMP
24 C3-8690 2 JUMPER-SHORT 120V
25 2E-Z10326 1 WIRE #17, WIRE KIT ASSEMLBY 120V
2E-Z10460 1 WIRE #17, WIRE KIT ASSEMLBY 230CE/240V
26 C3-Z5627 1 JUMPER 120V
C3-Z5625 1 LUG G12-120V
27 2T-6213 2 THERMOSTAT 120V (#G1205193 & BELOW)
2T-Y7422 2 THERMOSTAT 120V (#G1205194 & ABOVE)
2T-Y9453 2 THERMOSTAT 230CE/240V (#G1205218 & ABOVE)
28 2N-Y5592 1 ELEMENT HEATING 1420 WATT 120V
2N-Y5593 1 ELEMENT HEATING 1420 WATT 240V/230CE
29 2N-Y5594 1 ELEMENT HEATING 300 WATT 120V
2N-Y5595 1 ELEMENT HEATING 300 WATT 240V/230CE
30 2A-Y8027 1 SPACER-LONG
31 2A-Y8028 2 SPACER
32 2F-Z0019 1 PLATE-KETTLE
33 C3-G8029-PS 1 KETTLE LINER ASSEMBLY, STUDS
34 PS-G1499 1 HIGH LIMIT THERMOSTAT REPL. KIT 120V
2T-Z10182 1 HIGH LIMIT THERMOSTAT, manufactured after Aug. 2007 120V/230CE/240V
35 2E-Z10326 1 WIRE #17, WIRE KIT ASSEMLBY 120V
36 2E-Z10460 1 WIRE #17, WIRE KIT ASSEMLBY 230CE/240V
37 2C-Z0006 2 SCREW
38 2C-2556 2 NUT
39 2C-1825 2 LOCKWASHER
40 2C-1811 2 WASHER 1/4"
NI C3-Z5637 4 SLEEVING 4.5", WIRE 120V/240V
MODEL
PARTS LIST November 22, 2010, Rev. O
G12 TWELVE OUNCE KETTLE 120V/240V/230CE
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description
Part
Number
Key
Number
1
1
Star International Holdings, Inc. Company
To Next Page
