PARTS LIST December 12, 2011, Rev. O
G14/G18 120V/240V/230CE
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description
MODEL
Part
Number
Key
Number
- 2E-Y8802 1 RECEPTACLE - WALL 120V
- 2M-Y8601 1 LABEL STRIPE YELLOW/BLUE
- 2M-Y8352 1 LABEL STRIPE BLACK
1 2M-Z9300 1 LABEL-PANEL
2 2E-Z9310 2 SWITCH manufacture after serial number G1404363 G14
2E-Z9310 3 SWITCH manufacture before serial number G1404363 G14
2E-Z9310 2 SWITCH manufacture after serial number G1801677 G18
2E-Z9310 3 SWITCH manufacture before serial number G1801677 G18
3 C3-Y7952 1 BRACKET CATCH
4 2R-Y7844 2 CATCH MAGNETIC
5 C3-Y7953 1 COVER BRACKET
6 C3-Y7377 2 BRACKET HINGE-LEFT
7 C3-Y7446 2 BRACKET HINGE-RIGHT
8 C3-Y8188 1 LOWER DOOR
9 C3-Y7475 2 DOOR PULL ASSEMBLY
10 C3-G1476 1 LEFT DOOR ASSEMBLY
11 C3-G1475 1 RIGHT DOOR ASSEMBLY
12 2L-Y8863 1 CUP-OIL MEASURE 2 CUP (PLASTIC)
13 2L-Y8812 1 2 CUP MEASURE (PLASTIC)
14 2L-Y4916 1 SCOOP-POPCORN (PLASTIC)
15 C3-G1435 1 CORD SET ASSEMBLY 120V
C3-G8022 1 CORD SET ASSEMBLY 240V
2E-Z0151 1 CORD SET ASSEMBLY 230CE
16 2K-Y2968 1 BUSHING-STRAIN RELIEF 120V/240V
17 C3-Y8428 1 CORN DRAWER
18 2A-6904 4 FOOT
NI 2P-Y3404 4 PLUG
NI 2C-1557 4 SCREW 10 X 24-1 1/2 STL RHP
19 2E-Y2849 1 BLOCK TERMINAL
20 2P-6475 9 CLIP-TY
21 2N-Y8727 1 ELEMENT 80 WATT 120V
2N-Y8430 1 ELEMENT 80 WATT 240V/230CE
22 2K-Y1139 1 BUSHING HEYCO
23 2Q-Y7831 2 GLASS - SIDE
24 2I-Y7838 4 CHANNEL GLASS (SIDE - TOP & BOTTOM)
25 2I-Y7840 6 CHANNEL GLASS (UPRIGHT)
26 2Q-Y8605 1 GLASS-FRONT
27 2I-Y7839 2 CHANNEL GLASS (FRONT - TOP & BOTTOM)
28 2E-Y8212 1 LAMP SOCKET
2E-Y9433 1 SOCKET LAMP 230CE
29 2S-Y2238 1 LAMP - 250 WATT 120V
2S-Y8346 1 LAMP - 250 WATT 240V
2S-Y8712 1 LAMP -150 WATT 230CE
30 2B-Y7829 1 LAMP SHIELD
31 2E-Y8380 1 CONTACTOR 120V
2E-Y8381 1 CONTACTOR 240V - N/A ON 230CE VERSION
32 2E-Y8286 1 OUTLET LOCKING 120V
2E-Z0089 1 FLANGED OUTLET, 15A 250V 230CE/240V after 8/1/2002
2E-Y8290 1 OUTLET, LOCKING 15A, 250V 240V/ before 8/1/2002
33 2A-Y8645 1 PIN STOPPER - SHORT
34 2C-1811 2 BURR
35 2C-Y8646 1 SCREW
36 2A-Y8032 1 PIN STOPPER
1
2
Star International Holdings, Inc. Company
