27
PARTS LIST December 12, 2011, Rev. O
G14AT/G18AT 120V/240V/230CE
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description and Model Designation
MODEL
Part
Number
Key
Number
- 2E-Y8802 1 RECEPTACLE - WALL 120V G14
1 2M-Z9301 1 LABEL-PANEL-RED
2 2E-Z9310 2 SWITCH manufacture after serial number G1404363 G14
2E-Z9310 3 SWITCH manufacture before serial number G1404363 G14
2E-Z9310 2 SWITCH manufacture after serial number G1801677 G18
2E-Z9310 3 SWITCH manufacture before serial number G1801677 G18
3 C3-Y7952 1 BRACKET CATCH
4 2R-Y7844 2 CATCH MAGNETIC
5 C3-Y7953 1 COVER BRACKET
6 C3-Y7377 2 BRACKET HINGE-LEFT
7 C3-Y7446 2 BRACKET HINGE-RIGHT
8 C3-Y8188 1 LOWER DOOR
9 C3-Y7475 2 DOOR PULL ASSEMBLY (INC. IN DOOR ASSY.)
10 C3-G1478 1 LEFT DOOR ASSEMBLY
11 C3-G1477 1 RIGHT DOOR ASSEMBLY
12 2L-Y8863 1 CUP-OIL MEASURE 2 CUP (PLASTIC)
13 2L-Y8812 1 2 CUP MEASURE (PLASTIC)
14 2L-Y4916 1 SCOOP-POPCORN (PLASTIC)
15 C3-G1435 1 CORD SET ASSEMBLY 120V G14
C3-G8022 1/1 CORD SET ASSEMBLY 240V G14 / G18
2E-Z0151 1 CORD SET ASSEMBLY 230CE
16 2K-Y2968 1 BUSHING - STRAIN RELIEF - N/A ON 240VE VERSION
17 C3-Y8428 1 CORN DRAWER
18 2A-6904 4 FOOT
NI 2P-Y3404 4 PLUG
NI 2C-1557 4 SCREW 10 X 24-1 1/2 STL RHP
19 2E-Y2849 1 BLOCK TERMINAL
20 2P-6475 9 CLIP-TY
21 2N-Y8727 1 ELEMENT 80 WATT 120V
2N-Y8430 1 ELEMENT 80 WATT 240V/230CE
22 2K-Y1139 1 BUSHING - HEYCO
23 2Q-Y8512 2 GLASS - SIDE
24 2I-Y7838 4 CHANNEL GLASS (SIDE - TOP & BOTTOM)
25 2I-Y7840 6 CHANNEL GLASS (UPRIGHT)
26 2Q-Y8511 1 GLASS - FRONT
27 2I-Y7839 2 CHANNEL GLASS (FRONT - TOP & BOTTOM)
28 2E-Y8212 1 LAMP SOCKET
2E-Y9433 1 LAMP SOCKET 230CE
29 2S-Y2238 1 LAMP - 250WATT 120V
2S-Y8346 1 LAMP - 250WATT 240V
2S-Y8712 1 LAMP -150 WATT 230CE
30 2B-Y7829 1 LAMP-SHIELD
31 2E-Y8380 1 CONTACTOR 120V
2E-Y8381 1 CONTACTOR 240V - N/A ON 230CE VERSION
32 2E-Y8286 1 OUTLET LOCKING 20A 120V
2E-Z0089 1 OUTLET, STRAIGHT BLADE 230CE/240V
33 2A-Y8645 1 PIN STOPPER - SHORT
34 2C-1811 2 BURR
35 2C-Y8646 1 SCREW
36 2A-Y8032 1 PIN STOPPER
37 2F-Y8757 1 HANGER-REAR
38 2C-2581 2 NUT
1
2
Star International Holdings, Inc. Company.
