30
1
1
- C3-G1497 1 KETTLE ASSEMBLY COMPLETE 120V G14
- C3-G1495 1 KETTLE ASSEMBLY COMPLETE 230CE/240V G14
- C3-G1494 1 KETTLE ASSEMBLY COMPLETE 230CE/240V G18
1 2P-Y8285 1 PLUG 20A 125V 120V
2P-Z0017 1 PLUG, STRAIGHT BLADE 230CE/240V on or after 8/1/2002
2P-Y8289 1 PLUG 15A250V NEMA L6-15P, 230CE/240V before 8/1/2002
2 2K-3831 2 BUSHING
3 2E-Y8405 1 CONDUIT
4 2E-1177 1 CONNECTOR
5 2E-Y4967 1 WASHER
6 2E-Z10326 1 WIRE (GND) WIRE ASSEMBLY KIT 120V
2E-Z10461 1 WIRE (GND) WIRE ASSEMBLY KIT 230CE/240V
7 2E-Z10326 1 WIRE #15, WIRE ASSEMBLY KIT 120V
2E-Z10461 1 WIRE #15, WIRE ASSEMBLY KIT 230CE/240V
8 2E-Z10326 1 WIRE #16, WIRE ASSEMBLY KIT 120V
2E-Z10461 1 WIRE #16, WIRE ASSEMBLY KIT 230CE/240V
9 C3-G1417 1 SHELL ASSEMBLY
10 2C-2559 3 NUT-ACORN
11 2R-Y8892 1 HANDLE
12 2P-Y8092 1 RETAINING RING
13 2C-Y9767 2 WASHER
14 2P-Y8061 1 SPRING
15 2A-Y8891 1 ROD-CATCH
16 2A-Y8022 1 SET SCREW
17 2A-Y8051 2 STOPPER
18 2C-H8670 4 WASHER
19 2C-1493 4 SCREW
20 C3-Y7886-2 1 CHANNEL RUBBER
21 2C-1827 12 WASHER
22 2C-2560 12 NUT
23 C3-Y8133 3 CLAMP-ELEMENT
24 C3-Y8043 2 CLAMP
25 C3-Z5627 1 JUMPER 120V
2E-Z10461 1 WIRE #15, WIRE ASSEMBLY KIT 230CE/240V
26 2E-Z10326 1 WIRE #19, WIRE ASSEMBLY KIT 120V
2E-Z10326 1 WIRE #25, WIRE ASSEMBLY KIT 230V/240V
27 2E-Z10326 1 LUG-RIGHT, WIRE ASSEMBLY KIT 120V
C3-Y8335 1 LUG-RIGHT 240V
28 C3-Z5626 1 LUG 120V G14
30 2T-6213 2 THERMOSTAT 120V (#G1403752, G1801299 & BELOW)
2T-Y7422 2 THERMOSTAT 120V (#G1403753, G1801300 & ABOVE)
2T-Y9453 2 THERMOSTAT 230CE/240V (#G1403748, G1801300 & ABOVE)
2T-6213 2 THERMOSTAT 240V (BELOW #G1801299, ENCLOSED STYLE)
31 2N-8631 1 ELEMENT1600 WATT 120V G14
2N-8633 1/1 ELEMENT 1600 WATT 230CE/240V G14 / G18
32 2N-8634 1 ELEMENT 800 WATT 230CE/240V G18
2N-Y8283 1 ELEMENT 400 WATT 230CE/240V G14
2N-Y8282 1 ELEMENT 400 WATT 120V G14
33 2A-Y8275 1 SPACER-LONG
34 2A-Y8276 2 SPACER
35 2F-Z0020 1 PLATE-KETTLE
36 C3-G1422-PS 1 KETTLE LINER ASSEMBLY
37 PS-G1499 1 G14 & G18, HIGH LIMIT REPLACEMENT KIT 120V/230CE
2T-Z10182 2 HIGH LIMIT THERMOSTAT , manufactured after Aug. 2007 120V/230CE/240V
38 2E-Z10326 1 WIRE #24, WIRE KIT ASSEMBLY 120V/230CE/240V
39 2E-Z10326 2 WIRE #23, WIRE KIT ASSEMBLY 120V/230CE/240V
40 2C-Z0006 2 SCREW
41 2C-2556 2 NUT
42 2C-1825 2 LOCKWASHER
G14/G18 - 14/18 OUNCE KETTLE 120V/240V/230CE
PARTS LIST December 12, 2011, Rev. O
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description and Model Designation
MODEL
Part
Number
Key
Number
Star International Holdings, Inc. Company
