OPERATING AND SETUP INSTRUCTIONS
for GALKIN MODEL X5 SERGER FLANGER
1. INTRODUCTION
A. Machine Description
The Galkin 3350-X5 Serger Flanger was designed expressly for high speed attachment of
flanging to mattress pads
B. Galkin Customer Service
If you have any questions concerning the machine, or this manual, please feel free to
contact Galkin Automated Products, either by telephone or by fax.
Telephone number………………..(631) 643-5432
Fax number………………………..(631) 643-1472
C. Machine Specifications
Machine type…………………… Overlock with safety stitch
Top feed………………………… Patented Power Trac synchronized belt type
Stitch type (F.S.T.)……………… 516
Recommended sewing speed…… 4200 stitches per minute
Material thickness……………… Flat goods up to 6 inches (1 – 152mm)
Overall stitch width…………….. 15/16 inch (24mm) std. – 1-3/16 (30mm) option
Stitch length…………………….. 4-5 stitches per inch (.2s/mm)
Over edging width………………. 3/16 Inch
Distance to safety stitch………… ¾ inch (1” optional)
eedle size………………………. 135x7, #21
eedle height……………………. .56 inch (14.2mm)
Electrical (standard)……………. 220V – 1phase – 60Hz – ½ HP
Other voltages optional
Lubrication……………………… Automatic lubrication (sump); separate feed belt
oiler cartridge filter
