12
G
Power consumption 1,000 W
Mains voltage 230 V
Frequency 50 Hz
String strength 2 mm
Cutting width 330 mm
String supply 2 x 3 m
Weight approx. 4.5 kg
Rpm of filament cassette max. 12,000 rpm
IP-protector II
Moisture resistance covered
Working area related emission
characteristic value
L
pA
1)
83 dB (A)
Noise level L
WA
2)
measured 94 dB (A) / guaranteed 96dB (A)
Hand-arm vibrations
a
vhw
1)
< 2.5 ms
-2
on the handle / 3.3 ms
-2
on the additional handle
Measuring method according to
1)
EN 786
2)
Directive 2000/14/EC
GARDENA String Trimmer 1000
1. Technical data
Please read and follow these
operating instructions carefully.
Familiarise yourself with the unit’s
features, the controls, its proper
use and the safety instructions
included.
A
For safety reasons chil-
dren under the age of 16
or people who are not familiar
with these operating instruc-
tions should not use this
String Trimmer.
Please keep these operating
instructions in a safe place.
2. Information regarding the operating instructions
The GARDENA String Trimmer
has been designed for trimming
uncultivated areas, thick weeds
and tall grass in and around the
garden.
This trimmer is for private use
only and is not designed for use
in public places, parks, sport
arenas, street-scapes, in agricul-
ture or forestry.
It is essential to observe the
manufacturer’s operating instruc-
tions to ensure the unit’s proper
functioning. These instructions
also contain advice for service,
maintenance and repair.
A
Attention! For safety
reasons the unit must not
be used for hedge trimming
or for chopping up for com-
posting.
3. Proper use
Before beginning work, fix
and adjust the enclosed safety
cover
B
as well as the additional
handle
7
and the shoulder strap
6
as follows:
Insert the safety cover
B
into the
groove of the cutting head support
C
to the end stop according to
ill. A/A1. Listen for an audible
snap-in.
Not
e: Check whether the cover
is properly seated by lifting.
If the safety cover is properly
fastened, it is non-detachable
from the cutting head support.
A
Be careful with the cut-
ting blade/string limiter
0
, whilst assembling the
safety cover. Risk of injury!
Loosen the screws on the addi-
tional handle
7
and adjust the
handle to the most appropiate
working position according to
ill. A/A 2. Then firmly tighten the
screws.
Adjust the length of the shoulder
strap
6
according to ill. A/A3
to your size so that the String
Trimmer can be operated just
above the ground.
4. Assembly (ill. A)
