STEP 2:
Flip Bottom Rack (C) over to the opposite side and follow the instructions
provided in Step 1 to attach the remaining two Legs (B) to the Bottom
Rack.
*Do not tighten screws down completely during this portion of assembly.
Assembly Instructions
B
B
G
F
I
I
F
(1) M6x30mm Screw
G
(1) M6x35mm Screw
I
(2) 13 mm Washer
AFTER SALES SUPPORT 21
1800 599 8898 support@tdcusainc.com
MODEL: 22100-18 PRODUCT CODE: 55888 05/2018
USA
USA
SERVICIO POSVENTA
Instrucciones de ensamblaje
PASO 2:
Voltee el estante inferior (C) al lado opuesto y siga las instrucciones
provistas en el paso 1 para conectar las dos patas (B) restantes al
estante inferior.
* No apriete completamente los tornillos durante esta parte del ensamblaje.
B
B
G
F
I
I
F
(1) Tornillos M6 x 30 mm
G
(1) Tornillos M6 x 35 mm
I
(2) Arandela de 13 mm
